Modular
Triac Pill, Switch & Sensor
Features:
- Trailing Edge Control
- 3-wire type, Load, Live, Neutral
- Mobile App Addressable
- Additional wired push switch enabled
| Voltage/Frequency | Power(VA) | Load Type | Communication | Safety Standard | Operating Temperature |
|---|---|---|---|---|---|
| 220/240V AC -- 50~60Hz | 3 - 400 | R, C | Embedded Qualcomm Bluetooth | EN60669 | -20°C to 35°C |
DALI T8 Dimmer Pill, Switch & Sensor
Features:
- DALI Protocol
- No commissioning required
- Connect up to 4 master DALI in parellel
- Control up to 256 DALI ECGs
- DALI 2 certified
- CCT Adjustment Mode
- Mobile App Addressable
- Additional wired push switch enabled for active DALI MCU
| Voltage/Frequency | System Wattage(W) | Dimming Interface | Communication | Safety Standard | Operating Temperature |
|---|---|---|---|---|---|
| 220/240V AC -- 50~60Hz | 2.00 | DALI | Embedded Qualcomm Bluetooth | DALI 2 Certified | -20°C to 35°C |
1-10V Dimmer Pill, Switch & Sensor
Features:
- 2 control output
- CCT Adjustment Mode
- Mobile App Addressable
| Voltage/Frequency | Power(VA) | Load Type | Communication | Safety Standard | Operating Temperature |
|---|---|---|---|---|---|
| 220/240V AC -- 50~60Hz | Dimming 1 - 10V | R, C | Embedded Qualcomm Bluetooth | EN60669 | -20°C to 35°C |
Relay Pill, Switch & Sensor
Features:
- Mobile App Addressable
| Voltage/Frequency | Power(VA) | Load Type | Communication | Safety Standard | Operating Temperature |
|---|---|---|---|---|---|
| 220/230V AC -- 50~60Hz | 13A 3000VA Standby power 0.5W | R, C | Embedded Qualcomm Bluetooth | EN60669 | -20°C to 35°C |
BLE Power Node
Features:
- Mobile App Addressable
- Additional wired push switch enabled
- Serves as additional node to create mesh and broadcast command to other devices
| Voltage/Frequency | Communication | Safety Standard | Operating Temperature |
|---|---|---|---|
| 220/240V AC -- 50~60Hz | Embedded Qualcomm Bluetooth | EN60669 | -20°C to 35°C |
